25Gbps SFP28 Hardened Active Optical Cable

FIBERSTAMP 25Gbps SFP28 Hardened Active Optical Cables (HAOCs) are direct-attach fiber assemblies with SFP28 connectors, designed for short-reach interconnects. Featuring a hardened optical cable construction, they provide a cost-effective solution for connections within racks and between adjacent racks.

Each FIBERSTAMP SFP28 HAOC is built with a stainless steel tube, Kevlar reinforcement, and an LSZH jacket, supporting distances of up to 70 meters over OM3 multimode fiber. Engineered for long-term reliability and resistance to harsh environments, these cables deliver outstanding performance in demanding applications.

Description

Features
▪ Supports SFF8431/SFF8432/SFF8472,I2C management interface
▪ Hot-pluggable SFP28 form factor , supports 25Gbps data rate
▪ Maximum link length of 70m on OM3 MMF
▪ 850nm VCSEL laser and PIN photo-detector ▪ Internal CDR on both Transmitter and Receiver channel ▪ Single 3.3V power supply
▪ Power dissipation < 1W
▪ RoHS compliant ▪ Commercial case temperature range: -40°C to +85°C
▪ Hardened active optical cable with metal tube and Kevlar strengthen

Applications
▪ 25 Gigabit Ethernet ▪ EDR Infiniband
▪ High-performance computing clusters
▪ Servers, switches, storage and host card adapters

Additional Information

Application

, ,

Form Factor

Product Type

Protocol

Reach

Wavelength
