10Gbps USB 3.1 Type-A Male to Female Fiber Optic Cable
FIBERSTAMP introduces a cutting-edge 10Gbps USB 3.1 Type-C high-speed optical fiber cable to address stability, compatibility, and distance limitations of traditional copper wires in high-speed USB 3.1/3.0 signal transmission. It features a patented miniature diffraction system, ensuring stable performance, simple production, and custom casing options. This solution offers the most mature USB 3.1/3.0 optical fiber data transmission on the market.
Description
- Using 850nm VCSEL array technology
- The photoelectric module has a built-in miniature diffractive optical system designed by
- Alpha Optoelectronics patent
- Simple and quick production, mass production and operability
- No signal compression, no attenuation, support up to 30 meters lossless transmission
- High-speed signals are transmitted through two multimode optical fibers, which have good anti-interference performance
- Support hot swap
- Low power consumption, no external power supply required
Specifications
| Performance | |
|---|---|
| Protocol Specification | USB 3.1, USB 3.0, USB 2.0 (Copper Wire) |
| Transfer Rate | 10Gbps |
| Interface | |
| Input | USB Type-A Male |
| Output | USB Type-A Female |
| Power Supply | Low power consumption, no external power required |
| Cable | |
| Cable Specification | 2-core optical cable |
| Fiber Specification | 2-core multimode fiber |
| Standard Lengths | 1/2/5/10/15/20/25/30/40/50m |
| Maximum Length | 50m |
| Cable Jacket | TPE/85A |
| Color | Black |
| Cable Diameter | 4.3mm±0.15mm |
| Weight | Depends on length |
| Minimum Bend Radius | 12mm |
| Maximum Tensile Load | 221N |
| Environment | |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +80°C |
| Power | |
| Input Voltage | 5V |
| Power Supply Capacity | 900mA |
| Power Consumption | ≤500mW |
| Packaging | |
| Package Contents | Antistatic bag, cable ties, transmission line, user manual |
| Remarks | |
| During use, avoid excessive bending or breaking of the optical fiber. Please refer to the bend radius for details. | |
