Application scenarios of 5G carrying optical modules

  • Industry Insights

The 5G bearer network is generally divided into the metro access layer, the metro convergence layer, and the metro core layer/provincial trunk line to implement the forward and middle transmission functions of 5G services. Devices at each layer mainly rely on optical modules to connect. The typical application scenarios and requirements are analyzed as follows:

Network
Layer		Urban Access LayerUrban Convergence LayerUrban Core Layer
5G Front-Haul5G Middle-Haul5G Back-Haul + DCI5G Back-Haul + DCI
Distance<10/20km<40km<40-80km<40-80km/几百km
Network TopologyMain: Star Network
Back-up: Ring Network		Main: Ring Network
Back-up: Chain or Ring Chain Network		Ring Network or
Dual Uplink Link		Ring Network or
Dual Uplink Link
Client Interface
Data Rate		eCPRI: 25Gb/s

CPRI:
N×10/25Gb/s or
1×100Gb/s		Early 5G：
10/25Gb/s

Commercial Scale：
N×25/50Gb/s		Early 5G：
10/25Gb/s

Commercial Scale：
N×25/50/100Gb/s		Early 5G: 25/50/100Gb/s

Commercial Scale：
N×100/400Gb/s
Line Interface
Data Rate		10/25/100Gb/s
Gray Optics

or

N×25G/50Gb/s
WDM Color Optics
25/50/100Gb/s Gray Optics

or

N×25/50Gb/s
WDM Color Optics
100/200Gb/s Gray Optics

or

N×100Gb/s WDM Color Optics		200/400Gb/s Gray Optics

or N×100/200/400Gb/s
WDM Color Optics
